D Series UPS
- TEL:05-5873238
QR code
Products
Specification
| Model | NS-602M | NS-103M | NS-153M | |||||||
| Capacity | VA W |
2.4KVA |
3KVA |
3.5KVA |
6KVA |
8KVA |
10KVA |
12KVA |
15KVA |
20KVA |
| Max capacity | For 2 mins |
3.8KW |
4.8KW |
5.6KW |
9.6KW |
12KW |
15KW |
18KW |
22.5KW |
30KW |
| Input | Voltage | 200/220/230/240/380/400/415/440Vac±20％ | ||||||||
| Frequency | 50 or 60HZ±5% | |||||||||
| Phase | 1Φ2ω+G | |||||||||
| Output | Voltage | 200V/220V/230V/240V/380V/400V/415V/440Vac (Input=output) | ||||||||
| Frequency Stability | ±0.5％(Battery model) | |||||||||
| Voltage Regulation | <±1％(Battery model) | |||||||||
| Wave form | Sine-Wave | |||||||||
| Overload Capacity | 100% ~200% for 2 mins,>200% for 10 cycle | |||||||||
| Crest Factor | 3:1 | |||||||||
| Transfer Time | Bypass to ups for 5 seconds(Black out) | |||||||||
| Efficiency | ≧98%(Battery model ≧ 90％) | |||||||||
| Battery Voltage | 192Vdc | 240Vdc | ||||||||
| Battery Type |
12V/4Ah |
12V/4Ah |
12V/5Ah |
12V/7Ah |
12V/7Ah |
12V/9Ah |
12V/7Ah |
12V/9Ah |
12V/9Ah |
|
| Battery Quantity | 16pcs | 20pcs | 40pcs | |||||||
| Back up Time(PF=0.7) |
12mins |
8mins |
12mins |
7mins |
7mins |
6mins |
10mins |
9mins |
6mins |
|
| Recharge Time | 5 hours to 90% | 8hours to 90% | 16hours to 90% | |||||||
| Interface | Communication | Black out→Dry Contact ,Shutdown ups→5V~24Vdc | ||||||||
| Indicator | LED | Line(green),inverter(green),bypass(orange),battery(green),fault(red), overload(orange), Over charge(orange),battery level(5 LED indicators) |
||||||||
| Audible Alarm | Utility Power fail | Beeping every 4 seconds approx. 1 minutes auto alarm reset | ||||||||
| Low Battery | Rapid beeping every second as battery approaches final discharge | |||||||||
| Fault, Over Charge | Continuous | |||||||||
| Overload | Beeping 2 seconds on every other second | |||||||||
| Appearance | Dimension (W×D×H) |
240×585×638 mm | 265×634×735 mm | 285×670×895 +310×355×330 |
||||||
| Weight(kgs)/ 200V~240V 380V~440V |
75.5 81.5 |
100 |
120.5 |
128 |
130+50 |
141+55 |
153+55 |
|||
| Environment | Audible Noise | <50dB | ||||||||
| Operating Temperature | 0°C~40°C | |||||||||
| Humidity | 0%~90%(non-condensing) | |||||||||
